Description
- Anti-Corrosion Copper Heat Exchanger
- 2.0 TON HI-WALL ROTARY COMPRESSOR
TROPICAL INNOVATION SERIES FIXED TYPE SPLI
| Model | ASGA18BUTA-B NEW R-32 |
|---|---|
| Capacity | 1.5 Ton Cool : 5.30 kW |
| BEE Star Rating | 3 |
| Tonnage (TR) | 2.0 |
| Power Supply (Ph-Hz-V) | 10 -50-230 |
| Running Current (A) | 8.2 |
| Standard cooling at 100% capacity (min-max) (W) | 7050 |
| Power consumption at 100% capacity (min-max) (W) | 1,360 |
| Rated ISEER (kWh/kWh) | 3.81 |
| Electricity consumption per annum (kWh) | 1432 |
| Moisture removal (l/h) | 2.2 |
| Indoor fan speed control levels | 6 |
| Indoor air flow volume-high (m3/h) | 1230 |
| Indoor air flow distance (m) | 20 |
| Indoor unit dimensions HxWxD (mm) | 340x1150x280 |
| Indoor unit net weight (kg) | 17 |
| Outdoor unit dimension HxWxD (mm) | 752x910x330 |
| Outdoor unit net weight (kg) | 56.0 |
| Indoor noise level-quiet dB(A) | 38 |
| Connection pipe (gas/liquid) - (mm) | 15.88 / 6.35 |
| Pipe lenght min-max (percharged) (m) | 3~25 (5) |
| Max height difference - (m) | 10 |
| Ambient operating temperature range (0C) | 18 °C ~ 55 °C |
| Operating voltage range (V) | 195V ~ 265V |
| Refrigerant type (Non-CFC) | R32 |
| Compressor type | Hyper Tropical Rotary |
| Evaporator & condenser material | copper |
| Brands | O'GENERAL |
